Shandong Gold Drill is the source manufacturer of clamp-type flexible pipe joints, with full specifications and good quality.

Clamp-type flexible ring pipe joints are a special pipe connector, which is a pipe connection device that combines clamp-type connection and flexible design concepts.

1. Features: It has significant flexibility and sealing performance, can adapt to the displacement and deformation of the pipeline, and ensure the stability and sealing of the connection.

2. Structure and composition, main components: including pipe clamps (hoops), rubber sealing rings and fastening bolts. Sealing principle: The rubber sealing ring itself has self-tightening properties and relies on its own elasticity to press the main body of the pipe. The outer pipe clamp (hoop) will further compress the rubber sealing ring after tightening the bolts.

When the stamping pressure is running in the pipeline, the internal pressure will apply force to the C-shaped lip of the inner cavity sealing ring, so that the rubber sealing ring can compress the pipe more tightly. The higher the pressure within the design engineering pressure range, the better the sealing performance.

3. Performance and application, performance:

① High pressure resistance: It can withstand higher working pressure to ensure the safe operation of the pipeline system.

② Erosion resistance: Made of corrosion-resistant materials, it is suitable for pipeline systems with various corrosive media.

③ Good sealing performance: Through the close cooperation of the clamp and the sealing ring, the clamp-type flexible pipe joint can provide excellent sealing performance, effectively prevent leakage at the pipe connection, and can compensate for the displacement and deflection of the pipe due to thermal expansion and contraction.

④ Strong adaptability: The flexible design enables the clamp-type flexible pipe joint to adapt to the displacement and deformation of the pipe, and is suitable for various complex working environments. IV. Application: It is widely used in mining, chemical, petroleum, municipal engineering and water diversion projects, and is particularly suitable for providing sealed connections for positive and negative pressure pipelines for conveying water, compressed air, gas (coal gas), low-temperature steam, petroleum, milk (sugar liquid) products, slurry objects and dust (dry ash) and other media.

Example:

① For example, in the application of fire protection system, its quick connection and reliable sealing characteristics can ensure the normal delivery of fire protection water when a fire occurs.

② In the application of sewage treatment plants: It is used to connect various pipelines in the sewage treatment process, which can adapt to the displacement and deformation of the pipeline and ensure the stable operation of the sewage treatment system.

③ In the application of mining industry: In the pipeline system of water supply, drainage, ventilation and other pipelines in mines, the clamp-type flexible pipe joints can withstand the vibration and pressure changes in the mining environment and extend the service life of the pipeline.

4. Installation and maintenance, installation: When installing the clamp-type flexible pipe joints, ensure that the pipe ends are flat, the sealing rings are correctly in place, and the clamps are evenly tightened. Maintenance: During use, the sealing and tightening status of the joints should be checked regularly to ensure that they function normally to ensure the safety and efficiency of the pipeline system.

In ummary, the clamp-type flexible pipe joints have been widely used and recognized in many industrial fields with their unique structure and excellent performance.
